KM UM HD bloc
High-pressure membrane filter element for a squeezing pressure of up to 30 bar
High-pressure membrane filter elements are characterized by their high load capacity.
Thanks to special inlet designs and material combinations, these filter elements can withstand squeezing pressures of up to 30 bar.
Advantages
- Shorter filtration cycles
- Shorter washing times
- Higher dry solids content
- Higher throughput rate
- Reduced water consumption
- Reduced air consumption during blow-drying
- Squeezing pressure up to 30 bar
| Format: | From 470 mm to 1,500x2000 mm |
| Cake thickness: | From 15 mm to 50 mm |
| Filtration pressure: | Up to 8 bar |
| Squeezing pressure: | Up to 30 bar |
| Inlet position: | centre, off-centre, corner, external |
| Version: | C |
